| Parameters | |
|---|---|
| Product Name | ATS 10kWp Wall Mounted Battery |
| Nominal Capacity | 10.34kWh / 200Ah |
| Nominal Voltage | 51.2V |
| Battery Technology | Lithium Iron / LiFePO4 |
| Grouping capability | Up to 15P |
| Cycle Life | Up to 6000 cycles (At 80% DOD) |
| Weight | 93Kg |
| Dimension (mm) | 480 x 600 x 225 |
| Communication Interface | RS485, RS232, CAN (optional) |
